Ingersoll-Rand - Type-30 Air Compressors - Providing customer-driven air system solutions for more than 100 years. Back then, we called it "serving the customer." Today, we call it "Solutionizing" because your needs have changed and Ingersoll-Rand has evolved into a company focused on providing customer value. Ingersoll-Rand is committed to delivering product, service, and system solutions that save you money and make your business stronger and more successful by providing:
- Lower-life cycle cost.
- Unmatched durability.
- The ability to thrive in punishing applications.
- Economical and efficient solutions to maximize your business.
- Numerous configurations to meet virtually any need.
It's all about choices - Limited choices don't always meet your specific needs. That, in turn, limits your ability to maximize your operation. A supplier that understands your operation, helps solve your problems, and recommends a proper product for your application, optimizes your choices.
In today's market, there are too many misapplied compressors and poorly designed systems contributing to the problem instead of providing a solution. Ingersoll-Rand offers customers the expertise and scope to provide a proper solution. Ingersoll-Rand provides options and options lead to choices. Good choices lead to solutions and solutions lead to saving money through lower costs, increased productivity, improved quality and a better working environment.
-
Two-Stage Electric Driven Compressors - When unsurpassed performance is defined by maximum operating pressure, increased air flow and extended duty cycles, Ingersoll-Rand's Type-30 air compressor is the product of choice. The legendary Type-30 provides customers with the most dependable air supply to meet almost any application. Designed for the professional. From the small shop owner to the most demanding heavy-duty industrial and automotive applications, there is a Type-30 package to fit your needs.
- Value Package 5-15 HP - The Type-30 Value Package offers customers an economical and dependable compressed air solution. It is perfect for commercial, automotive, and light industrial applications.
- Durable 100% cast iron construction.
- Automatic start/stop pressure switch operation.
- Manual tank drain.
- Intermittent duty cycle.
- Fully Packaged 5-25 HP - This is the original. Powerful, durable, reliable, built to last. A legend from the very beginning. Perfect for automotive, heavy-duty commercial and industrial applications where added features and protection are needed.
- Type-30 standard scope with added features and values.
- Automotive start/stop pressure switch operation (5-7.5 HP).
- Centrifugal unloader (10-25 HP).
- Fully packaged for improved air quality and safety monitoring.
- Features heavy-duty, two-stage inlet filters (20-25 HP).
- Extended duty cycle.
- "Deluxe" Fully-Packaged (5-20 HP) - The deluxe, fully-packaged compressor systems are designed for applications where maximum efficiency, reliability and flexibility are required. These units operate at a slower RPM resulting in lower operating temperatures, maximum efficiency and extended pump life. In short, more air per horsepower. Features include a "fully adjustable" pressure switch (both operating pressure and delta pressure) that allows for synchronization of the delivered air pressure to more closely match application requirements. Perfect for manufacturing and rigorous industrial applications, where a more demanding, full-featured compressor solution is required.
- 100% cast iron pump rated for 15,000+ hours.
- Increased air flow per horsepower.
- Mounted and wired motor starter (NEMA 1).
- Glycerine-filled industrial pressure gauge.
- Fully adjustable pressure switch (both pressure and delta pressure).
- Centrifugal unloader.
- Start-up kit with "two-year package warranty" included.
-
Two-Stage Gas-Powered Air Compressors - Ingersoll-Rand's two-stage gasoline engine driven air compressors are designed to provide compressed air where electric power is not readily available. Perfect for fleet and field service applications, remote pneumatic applications, and emergency production line needs.
- Available with easy starting Honda, Kohler, or Kawasaki engines.
- Fuel efficient idle control.
- Honda 9 HP with pull or electric start, low oil level shutdown.
- Honda 13 HP with 12 volt electric starter, pull start, gas tank, low oil level shutdown, and 3 amp recharging system.
- Kohler 12.5 HP with 12 volt electric starter and gas tank.
- Kawasaki 11.5 HP with 12 volt electric starter, gas tank, and low oil pressure shutdown.
- Pressure Lube (20 and 25 HP) Fully Packaged - Ingersoll-Rand pressure lubricated compressors provide positive lubrication to all critical components, including crankshaft bearings, rod journals, and wrist pins. This extends the life of these components and allows the compressor to run on a continuous duty cycle. Our superior lubrication system utilizes a positive displacement oil pump with a mounted oil pressure gauge to provide a visual indication of oil pressure. Perfect for extreme duty industrial, high dust, and automotive applications.
- Precision balanced pistons for smooth, vibration-free operation.
- Rifle-drilled crankshaft for pressure lubrication to critical components.
- Heavy-duty, two-stage inlet filter with a pre-cleaner and high dust ejector valve.
- Hydraulic unloader included to ensure load-free starting and protection against loss of lubrication.
- State-of-the-art lubrication system including oil pump, filter, wye-strainer, low oil level switch, sight glass, and optional low-oil pressure shut down protection.
- Oil filter allows for extended oil life and run-time under harsh conditions.
- Available 250 psi option, suitable for continuous duty operation.
Jenny/Emglo - Industrial Stationary Air Compressors
-
Base Plate Mounted
Standard Features:
- Heavy-duty single or two stage cast iron compressor pump.
- Made in Somerset, PA USA.
- Splash lubricated.
- Belt driven with a large flywheel for extra cooling and easier start-up.
- Each unit is filled with Jenny Synthetic Blue Compressor Pump Oil.
- Directional air shroud for reduced pump temperatures.
- Totally enclosed heavy-duty belt guard.
- Powder coated, extra heavy steel base plate.
- Large canister intake filter with replaceable filter elements.
- Pressure relief safety valve.
- Pressure gauge.
Electric Powered Model Features:
- Auto Start/Stop control with pressure unloader set at 105-125 PSI.
- Control group (not mounted).
- Check Valve.
- Magnetic starter is included on all 5 HP and larger units.
- Industrial/Commercial grade UL Listed electric motor.
- Thermal overload motor protection.
Gas Powered Model Features:
- Constant run control set at 105-125 PSI (single stage) or 145-175 PSI (two stage).
- High quality pilot valve.
- Pneumatic throttle idle control.
- Honda GX Series OHV Engine or Kohler OHV V-Twin Engine.
-
Electric Stationary
Standard Features:
- Heavy-duty single or two stage cast iron compressor pump.
- Made in Somerset, PA USA.
- Splash lubricated.
- Belt driven with a large flywheel for extra cooling and easier start-up.
- Each unit is filled with Jenny Synthetic Blue Compressor Pump Oil.
- Directional air shroud for reduced pump temperatures.
- Totally enclosed heavy-duty belt guard.
- Tanks are powder coated and ASME certified.
- 60 gallon tanks and larger are ASME National Board Certified.
- Protectively mounted fittings.
- Manual tank drain(s).
- Large canister intake filter with replaceable filter elements.
- Special unloading valves to assist in motor starting.
- Pressure relief safety valve.
- Auto Start/Stop control with pressure unloader set at 105-125 PSI.
- Magnetic starter is included on all 5 HP and larger units.
- Industrial/Commercial grade UL Listed electric motor.
- Thermal overload motor protection.
- Alternator and magnetic starter are standard on all duplex models.
-
Climate Control
Standard Features:
- Heavy-duty cast iron compressor pump.
- Made in Somerset, PA USA.
- Splash lubricated.
- Belt driven with a large flywheel for extra cooling and easier start-up.
- Each unit is filled with Jenny Synthetic Blue Compressor Pump Oil.
- Directional air shroud for reduced pump temperatures.
- Totally enclosed heavy-duty belt guard.
- Tanks are powder coated and ASME certified.
- 60 gallon tanks and larger are ASME National Board Certified.
- Protectively mounted fittings.
- Manual tank drain(s).
- Large canister intake filter with replaceable filter elements.
- Special unloading valves to assist in motor starting.
- Tank gauge.
- Pressure relief safety valve.
- Auto Start/Stop control with pressure unloader set at 75-100 PSI.
- Magnetic starter is included on all 5 HP and larger units.
- Industrial/Commercial grade UL Listed electric motor.
- Thermal overload motor protection.
- Alternator and magnetic starter are standard on all duplex models.
-
Fire Sprinkler Stationary
Base Plate Mounted Standard Features:
- Heavy-duty cast iron compressor pump.
- Made in Somerset, PA USA.
- Splash lubricated.
- Belt driven with a large flywheel for extra cooling and easier start-up.
- Each unit is filled with Jenny Synthetic Blue Compressor Pump Oil.
- Directional air shroud for reduced pump temperatures.
- Totally enclosed heavy-duty belt guard.
- Powder coated, extra heavy steel base plate.
- Large canister intake filter with replaceable filter elements.
- Magnetic starter is included on all 5 HP and larger units.
- Industrial/Commercial grade UL Listed electric motor.
- Thermal overload motor protection.
Tank Mounted Additional Standard Features:
- Tanks are powder coated and ASME certified.
- Protectively mounted fittings.
- Manual tank drain(s).
- Large canister intake filter with replaceable filter elements.
- Special unloading valves to assist in motor starting.
- Tank gauge.
- Pressure relief safety valve.
- Auto Start/Stop control with pressure unloader set at 25-40 PSI.
Saylor-Beall - Pressure/Splash Lubricated Air Compressors - Quality and durability begin with design. Saylor-Beall products use materials selected for outstanding strength, wear and heat resistant characteristics. Exacting dimensions and precision tolerances result in a highly efficient air compressor design.
Computer controlled, state-of-the-art equipment perform machining operations with extreme accuracy. In addition, modern quality control procedures continuously monitor the machining process.
The design of Saylor-Beall's pressure lubricated air compressors is especially well suited for industrial environments where extreme operating conditions demand excellence in air compressor design and quality.
High-temperature environments, high duty-cycle service, and applications where other forms of lubrication are unacceptable indicate the need for pressure lubricated systems.
A gear type rotary oil pump mounted at the end of the crankshaft, coupled with rifle drilled crankshaft and connecting rods provide pressurized oil flow to the parts of the compressor that most need lubrication - the crankshaft, connecting rods and piston pins. This system dramatically increases the service life of the compressor.
All Saylor-Beall air compressors are available with optional pressure lubrication.
Our most popular models...
- Horizontal Tank Mounted Units
- Electric Motor or Gasoline Engine
 |
- Vertical Tank Mounted Units
- Electric Motor
 |
- Base Mounted Units
- Electric Motor
 |
- Duplex Units
- 2 Electric Motors
- 2 Compressor Pumps
 |
Quincy - High Pressure compressors - Quincy Compressor, where you not only get world class air compressors, you also get decades of experience in the design and operation of energy efficient compressed air systems. Our air compressors and vacuum pumps can be found in the most demanding and critical installations. Thats why thousands of people and industries count on Quincy quality and reliability!
- Single-Stage Basic Compressor
 |
- Two-Stage Basic Compressor
 |
Special requests/quotes available.
|
|
|
